Knurled Thumb Knob Male Thread Type 1

Knurled thumb knob male thread design 1.jpg (29877 bytes)

knurled thumb knob male thread 1.jpg (9727 bytes)

Fastenright Limited Your Uk Source For Fixings & Fasteners.



Technical Data & Available Sizes

Click below for 'Type 2'

Knurled Thumb Knob Male Thread Type 2

SIZES AVAILABLE
PART NO D H d d1 d2 C h h1
J23-15 15 10 10 M4-5 8 5.5 4.5 8.5
J23-21 21 15 13 M5-6 9.5 8.5 6.5 12.5
J23-26 26 18 16 M6-8 12 9.5 8.5 15
J23-33 33 23 20 M8-10 15 12.5 10.5 18
L Thread Length by request
